Features:
• Motor current adjustable with DIP switches from 2.0A to 5.0A in 0.2A steps (peak values, max. effective current 3.5A)
• Singe supply voltage 15-45V=
• Fullstep down to 1/16 microstep
• Output protected against short circuit
• Galvanic isoltation on all digital I/O with optocouplers
• All I/O supplied with screws Phoenix plugs
• Significantly reduced power losses, compared to the HP-Step driver the power consumption is reduced up to 35%
• Dimensions only 146*77*25mm
• Quality made in germany
• Different options available on demand, e.g. analog speed control, motor brake, encoder input, bus interface etc.

included in delivery:
• tested board
• I/O connectors
• manual
